爱泽工业部分到货产品专题及库存——INGETRANS篇
|
如下为我司爱泽工业IZE_Industries本月部分到INGETRANS相关产品，欢迎致索取样本资料和产品信息。   INGETRANS减速机PG.0502CPC 爱泽工业 ize-industries   INGETRANS减速机PG.0702CPC 爱泽工业 ize-industries
行星齿轮装置在动力传动领域的使用是对紧凑性、结构简单性和产品可靠性需求的现代解决方案。 PG行星齿轮装置根据要传递到输出轴的不同扭矩分为21个基本组，其范围从0.05到65 kNm不等。 事实上，SOM 产品模块化结构允许将锥齿轮、蜗轮、液压制动器和各种输入轴连接到行星单元，并为液压或电动马达提供多种连接法兰选择。 行星齿轮装置的模块化构造技术提供的另一个优点是可以安装一系列不同尺寸的级以获得广泛的减速比。 SOM产品系列在单级装置上提供从3:1到7:1的减速比，在5级装置上提供高达10.000:1和更多的减速比。 输出轴和法兰的广泛选择简化了工业机械或工厂上的减速装置安装操作。 The use of planetary gear units in the field of power transmission is the modern answer to the demand for compactness,constructive simplicity and product reliability. PG planetary gear units are divided into 21 basic groups depending on the different torques that are to be transmitted to the output shaft,which can vary from 0.05 to 65 kNm. In fact,the SOM product modular construction permits the coupling of bevel gears,worm gears,hydraulic brakes and a variety of input shafts to the planetary units,as well as providing for a wide choise of coupling flanges for hydraulic or electric motors. Another advantage offered by the modular construction technique of the planetary gear units is the possibility to mount a series of stages of different sizes in order to obtain a vast range of reduction ratios. The SOM product range provides reduction ratios from 3:1 to 7:1 on a single stage unit up to 10.000:1 and more on a 5 stage unit. The wide selection of output shafts and flanges simplifies the reduction unit mounting operation on industrial machinery or plants.
|
